Case Study: MISSION CRITICAL MOTION CONTROL

Challenge

A major US Navy defense contractor required a precise motion control solution for loading and unloading of projectiles, cannon rotation, azimuth and elevation control for the gun system. The mission critical solution precisely delivers projectiles with a mass of 225 lb (102 Kg) at a rate of fire of 10 rounds per minute.

POWERTEC Solution

POWERTEC Permanent Magnet AC Motors

ApplicationPerformanceWeight
Elevation control93hp (69KW) @ 2000 RPM553 lb (251Kg)
Azimuth control33hp (24KW) @ 1500 RPM297 lb (135Kg)
Projectile feeding15hp (11KW) @ 3600 RPM151 lb (68Kg)
Projectile extraction6.5hp (5KW) @ 3300 RPM107 lb (48Kg)

Benefits

  • Rugged construction to meet Navy Service A duty and high shock impacts up to 200G (Grade A)
  • Modular designs, 4 motor sizes can accommodate 18 different performance configurations
  • Designed to fit special mountings, electrical interfaces and MIL-Spec paints/coatings

RESULTS

POWERTEC partnered with the customer to design and manufactured lightweight, compact and highly effective PMAC motors to meet Navy Service A duty and high shock impacts up to 200G (Grade A).
